Direct Metal Laser Solidification (DMLS®)

DMLS

Direct Metal Laser Solidification (DMLS®), is the process of manufacturing metal parts from 20-40-micron powders with 400W lasers. These lasers fuse microlayers of fine metal together to create complex geometries from 3D design files. Because DMLS® melts and forges metal powders repetitively, the process ensures 99.9% uniquely uniform densities throughout the parts.

The powdered metal is first spread by a sliding arm on the print platform. Then, the powdered metal is laser fused and lowered by a distance equal to a single micron powder layer. This entire process is repeated on tens of thousands of layers until a fully-functional production part is formed. Once the process is finished, the part is ready to be Wire EDM precision-cut from the build platform.

DMLS® machines produce parts that are known for their strength, hardness, and densities–each of which are comparable to or better than those of machined, cast, or forged parts of similar metals. In many cases, the rapid solidification rate, after the laser fusing, creates a very fine crystal structure with superior strength to forged or cast components. If the DMLS® part is heat treated, its density, durability, and strength are even greater.

Because of the superior quality and unique manufacturing process, DMLS® machines allow for design freedom. Designs can be built hollow or filled for even higher strength-to-weight ratios. From aerospace to firearms, find out how DMLS® can is used in your industry.

I am text block. Click edit button to change this text. Lorem ipsum dolor sit amet, consectetur adipiscing elit. Ut elit tellus, luctus nec ullamcorper mattis, pulvinar dapibus leo.

EOS DMLS® M280

Direct Metal Laser Sintering M280

The EOS M280 is the work horse of EOS Direct Metal Laser Solidification (DMLS®) printers. It produces production parts using fully automated laser sintering driven by Solidworks CAD files, no CNC programming, no tool changes necessary.

Constant system self-monitoring of the build process ensures that all parts are printed in fully functional, reproducible quality. 3D metal printing allows clients to design and manufacture products with extremely complex geometries including free-form surfaces, lattice and honeycomb structures, deep slots, and conformal cooling channels.

The Basics

  • 3D Manufacturing of metal, fully functional, production parts
  • Aluminum, Titanium, Inconel, Hastelloy X, Haynes (214,242, 282), Maraging (Tool) Steel, Stainless Steel, Copper in stock
  • Open parameter sets for custom powder and 3D production efficiencies
  • Cost efficient manufacturing of high quality metals is small to medium-size runs
  • Reduce weight by 70% with latticed & honeycomb geometries
  • Reduced lead times to hours, days or weeks
  • Rapid prototyping and manufacturing made easy with Solidworks, Raw files, and .Step files

Key Statistics

  • Net build size: 228 x 228 x 190 mm (9 x 9 x 7.5 inches)
  • Minimum Feature size = .015’’ or .38 mm
  • Minimum wall thickness is .3mm – .4mm or .012” – .014”
  • Layer Thickness = 20 or 40 microns
  • Typical held tolerances are +/- .005″ on 1st in, +/- .002″ thereafter

EOS DMLS® M290

Direct Metal Laser Sintering M290

i3DMFG™ is proud to have the first EOS M290 DMLS® machine in North America. The EOS M290 is the latest in DMLS® excellence. Using the highly reliable M280 as it base, the M290 adds improved energy efficiencies, faster build times, and slightly larger build platform capabilities. i3DMFG™ clients gain the benefits of years of M280 proven applications while accessing the latest in DMLS® technology.

The Basics:

  • 3D Manufacturing of metal, fully functional, production parts
  • Aluminum, Titanium, Inconel, Hastelloy X, Haynes (214,242, 282), Maraging (Tool) Steel, Stainless Steel, Copper in stock
  • Open parameter sets for custom powder and 3D production efficiencies
  • Cost efficient manufacturing of high quality metals is small to medium-size runs
  • Reduce weight by 70% with latticed & honeycomb geometries
  • Reduced lead times to hours, days or weeks
  • Rapid prototyping and manufacturing made easy with Solidworks, Raw files, and .Step files

Key Statistics:

  • Net build size: 250 x 250 x 300mm
  • Minimum Feature size = .015’’ or .38 mm
  • Minimum wall thickness is .3mm – .4mm or .012” – .014”
  • Layer Thickness = 20 or 40 microns
  • Typical held tolerances are +/- .005″ on 1st in, +/- .002″ thereafter

EOS DMLS® M400.4

EOS® M400.4 is the ultra-fast four Direct Metal Laser Solidificiation(DMLS®) machine which provides high quality production parts. i3DMFG™ currently is running production parts on two EOS® M400.4 machines. The M400.4 has a larger build envelope than our EOS M290 machines and the processes can be transferred while retaining equivalent part properties.

The Basics:

  • 3D Manufacturing of metal, fully functional, production parts
  • Aluminum, Titanium, Inconel, Hastelloy X, Haynes (214,242, 282), Maraging (Tool) Steel, Stainless Steel, Copper in stock
  • Open parameter sets for custom powder and 3D production efficiencies
  • Cost efficient manufacturing of high-quality metals is small to medium-size runs
  • Reduce weight by 70% with latticed & honeycomb geometries
  • Reduced lead times to hours, days, or weeks
  • Rapid prototyping and manufacturing made easy with Solidworks, Raw files, and .Step files

Key Statistics:

  • Net build size: 400 x 400 x 400 mm (15.8 x 15.8 x 15.8 inches)
  • Minimum Feature size = .015’’ or .38 mm
  • Minimum wall thickness is .3mm – .4mm or .012” – .014”
  • Layer Thickness = 20 or 40 microns
  • Typical held tolerances are +/- .005″ on 1st in, +/- .002″ thereafter

Metals We Print

i3DMFG™ is one of the few 3D manufacturers in the US that specializes in aluminum, copper, titanium, Inconel, Haynes, Monel K, Stainless Steel and custom metal powder applications. Experts in 3D design, our engineers help our customers achieve competitive advantage in design and proprietary advancements.

Aluminum (AlSi10 and 6061)

Due to its lightweight nature and excellent thermal properties, AlSi10 is our most common DMLS aluminum powder. It is ideal for parts with thin walls and complicated geometries. i3DMFG™ also runs 6061 to achieve better surface finish and strength properties comparable to wrought 6061-T6.

Titanium (Ti)

Titanium (Ti64) is well suited for projects requiring corrosion resistance, strength, weight reduction, and biocompatibility.

Stainless Steels (15-5, 17-4, 304L, and 316L)

DMLS® stainless steel is a medical grade, sterilisable, corrosion resistant steel that hardens to 40-45 HRC after heat treatment. Our stainless-steel equivalents include 15-5, 17-4, 304L, and 316L. Parts made from DMLS® can be machined, spark-eroded, welded, micro shot-peened, polished, and coated.

Maraging Steel (MS1)

Maraging (tool) Steel (MS1) features excellent strength and mechanical properties. Its chemical composition corresponds to U.S. 18% Ni Maraging 300, European 1.2709 and German X3NiCoMoTi 18-9-5. After heat treatment, MS1 typically has a 50-53 HRC.

Super Nickle Alloys (IN625, IN718, Haynes 214, 242, 282 and Hastelloy X)

Super Nickle alloys are chromium alloys with superior heat and corrosion resistance.

Copper (GrCop-84 and GrCop-42)

i3DMFG™ is developing parameter sets to print in GrCop-84 and GrCop-42 for high temperature applications.

A NASA developed Copper alloy that is highly conductive for the aerospace industry.

Custom Powders

i3DMFG™ is the market leader is DMLS® powder development. We are able to develop highly specialized powder applications for aerospace, UAV/UAS, rocket, defense, oil & gas, energy, medical device, automotive, and casting customers.[/
